Rotavator

Uneven seedbeds and clumpy soil slow everything down after ploughing, from sowing precision to final crop stand. As a leading rotavator manufacturer, Shakti Agrotech builds rotavators that pulverize soil in a single pass, turning rough, freshly ploughed fields into a fine, level seedbed ready for planting cutting down the extra passes many farmers end up making after tillage.

The range is built to match different tractor classes and field sizes, so dealers and farmers aren’t stuck choosing between something too light for the job or too heavy for their fleet. The Mini series (0.8M, 1.0M, 1.2M) is suited to compact tractors running 12 to 35 HP, with tilling widths from 34.92″ to 49.33″ and 16 to 24 tines on a reliable gear-driven transmission. It’s a practical fit for smallholders, kitchen gardens, and lighter fieldwork where manoeuvrability matters as much as power.

For larger operations, the SRT series (SRT 4 through SRT-10) scales all the way up to 90 HP, with tilling widths stretching beyond 83 inches and tine counts reaching 72 on the biggest models. This series is offered across four configurations Regular, Regular Plus, Semi Champion, and Semi Champion Plus giving buyers flexibility on mast type and build weight depending on soil conditions and how the implement will be used. Higher-capacity models in this range come fitted with a slip clutch or shear bolt driveline safety device, protecting the tractor’s PTO from sudden shock loads when working stony or uneven ground.

Every model in the lineup runs on a gear transmission for consistent, dependable power delivery, with tine construction options suited to different soil types and working depths up to 6 inches. That consistency matters most during peak season, when downtime isn’t an option.

Whether you’re a farmer preparing a few acres for the next crop or a dealer stocking machinery across multiple HP classes, this range offers a rotavator sized to the tractor and the terrain. Backed by a strong, durable frame, low-maintenance operation, and easy access to spare parts, it’s engineered for reliable performance season after season.

2F 350-101214

2F 380-101214

1 / 3
SPECIFICATION / MODEL Mini 0.8M Mini 1.0M Mini 1.2M Mini 1 MTR Mini 1.2 MTR
Overall Length (mm) 1023 1206 1389
Overall Width (mm) 670 670 670
Overall Height (mm) 949 949 949
Tilling Width (mm) 887 1070 1253
Tilling Width (inch) 34.92 42.12 49.33
Tractor Power (HP) 12-22 15-25 25-35
Tractor Power (Kw) 12-22 13-22 21-30
3-Point Hitch Type
Frame Off-set (mm / inch)
Number of Tines (L/C - 90x8) 16 20 24
Number of Tines (L/C - 80x7)
Standard Tine Construction
Transmission Type GEAR GEAR GEAR GEAR GEAR
Max. Working Depth (mm/inch) 152/6 152/6 152/6
Rotor Tube Diameter (mm/inch) 73/2.9 73/2.9 73/2.9
Rotor Swing Diameter (mm/inch) 412 412 412
Driveline Safety Device
Weight (Kg) 167 177 201
Weight (lbs) 369 319 444
SPECIFICATION / MODEL SRT-4 SRT-5 SRT-5.5 SRT-6 SRT-7 SRT-8 SRT-9 SRT-10
Overall Length (mm) 1402 1778 1937 2014 2247
Overall Width (mm) 900 900 900 900 900
Overall Height (mm) 1120 1120 1120 1120 1120
Tilling Width (mm) 1269 1615 1804 1881 2114
Tilling Width (inch) 49.96 63.58 71.02 74.05 83.22
Tractor Power (HP) 40-55 45-60 50-65 55-70 65-80
Tractor Power (Kw) 34-47 38-51 42-55 47-60 55-68
3-Point Hitch Type CUT-II CUT-II CUT-II CUT-II CUT-II CUT-II CUT-II CUT-III
Frame Off-set (mm / inch)
Number of Tines (L/C - 90x8) 30 36 36/39/42 42 48
Number of Tines (L/C - 80x7)
Standard Tine Construction
Transmission Type GEAR GEAR GEAR GEAR GEAR GEAR GEAR GEAR
Max. Working Depth (mm/inch) 178/7 178/7 178/7 178/7 178/7
Rotor Tube Diameter (mm/inch) 89/3.5 89/3.5 89/3.5 89/3.5 89/3.5
Rotor Swing Diameter (mm/inch) 480/18.89 480/18.89 480/18.89 480/18.89 480/18.89
Driveline Safety Device
Weight (Kg) 406 448 472 489 540
Weight (lbs) 895 988 1041 1190 1190
SPECIFICATION / MODEL SRT-4 SRT-5 SRT-5.5 SRT-6 SRT-7 SRT-8 SRT-9 SRT-10
Overall Length (mm) 1414 1760 1880 2026 2259 2481
Overall Width (mm) 959 959 959 959 959 959 959 959
Overall Height (mm) 1135 1135 1135 1135 1135 1135 1135 1135
Tilling Width (mm) 1269 1615 1804 1881 2114 2336
Tilling Width (inch) 49.96 63.58 71.02 74.05 83.22
Tractor Power (HP) 40-55 45-60 50-65 55-70 65-80 75-90
Tractor Power (Kw) 34-47 38-51 42-55 47-60 55-68 68-77
3-Point Hitch Type CUT-II CUT-II CUT-II CUT-II CUT-II CUT-II CUT-II CUT-III
Frame Off-set (mm / inch)
Number of Tines (L/C - 90x8) 30 36 36/39/42 42 48
Number of Tines (L/C - 80x7) 54 66 72
Standard Tine Construction
Transmission Type GEAR GEAR GEAR GEAR GEAR GEAR GEAR GEAR
Max. Working Depth (mm/inch) 178/7 178/7 178/7 178/7 178/7 178/7 178/7 178/7
Rotor Tube Diameter (mm/inch) 89/3.5 89/3.5 89/3.5 89/3.5 89/3.5 89/3.5 89/3.5 89/3.5
Rotor Swing Diameter (mm/inch) 480/18.89 480/18.89 480/18.89 480/18.89 480/18.89 480/18.89 480/18.89 480/18.89
Driveline Safety Device Slip Clutch / Shear Bolt Slip Clutch / Shear Bolt Slip Clutch / Shear Bolt Slip Clutch / Shear Bolt Slip Clutch / Shear Bolt Slip Clutch / Shear Bolt Slip Clutch / Shear Bolt Slip Clutch / Shear Bolt
Weight (Kg) 421 462 483 500 536 578 648 690
Weight (lbs) 928 1019 1065 1102 1182 1274 1429 1521
